Model |
ATV120K |
ATV150K |
|
Engine |
13.5HP E-start B&S engine |
|
|
Engine max power |
15PS |
|
|
Working width |
1150mm |
1450mm |
|
Recommended grass height |
<35cm |
|
|
Adjustable mowing height |
20-70mm |
|
|
Dimensions(L*B*H)cm |
200*187/146*112 |
200*217/176*112 |
|
Total weight |
281kg |
312kg |
|
Tire size |
16’’*6.5’’-8’’ |
|
|
Trailer connector |
Ball head coupling 50mm |
|
|
Working efficiency |
2100-2500㎡/h |
2500-3000㎡/h |
|
Drive system |
2 belt system 17mm, centrifugal clutch |
|
|
Displacement |
420ccm |
|
|
Starter |
Recoil starter(E-starter optional) |
|
|
Fuel tank |
6.5L |
|
|
Fuel consumption |
ca. 1.5-2.0L/Std. |
|
|
Fuel |
Super E10 unleaded |
|
|
Rotor shaft diameter/material strength |
108mm/8mm |
|
|
Rotor roller diameter/material strength |
102mm/5mm |
|
|
Material strength mower housing |
4mm |
|
|
Material strength side walls |
6mm |
|
|
Painting |
Powder coating |
|
|
Flail type |
Flail hammer, forged and galvanized |
|
|
Number of flails |
28 |
32 |
|
Weight per flail hammer |
320g |
|
|
Rotor RPM recommended/max |
2500/3200 |
|
|
Packing size(wooden box) |
190*105*110cm |
221*105*110cm |
|
40’’ container |
22pcs(wooden box) 33pcs(iron palate) |
|
-
