WP-23E/ WP-23G

市 场 价:¥0

优 惠 价:¥0

库  存:999

选择商品:

商品详细

Model

WP-23E

WP-23G

Max compressive force

23 Ton

23 Ton

Max diameter of wood

280mm

280mm

Max length wood

200-650mm

200-650mm

Cut logs length

2900mm

2900mm

Power

380V/50HZ, 4KW, 3 phase

6.5HP China Gasoline Engine

Hydraulic pump

Ca 25 lit/min, 220 bar

Ca 25 lit/min, 220 bar

Hydraulic oil

32L

32L

Split time

8 sec. down/5 sec. up

8 sec. down/5 sec. up

Capacity

18m3 / 8h

18m3 / 8h

Wood slices

2-4

2-4

Towable behind a car

30km/h

30km/h

Coupler

50mm-EU

50mm-EU

Piston diameter

100/80 x 300 mm

100/80 x 300 mm

Tyre

16*6.5-8

16*6.5-8

Weight

245/300kg

245/300kg

20’’/40" Container

29/60pcs

29/60pcs

Size

3000x1200x1980mm

3000x1200x1980mm
