商品详细
|
Model |
HW1700 |
HW1700R |
|
Maximum Traction(20Mpa) |
1700kg |
1700kg |
|
Operating Pressure |
16-20Mpa |
16-20Mpa |
|
Hydraulic Valve |
Manual |
Remote |
|
Motor Displacement |
400cc/380Nm |
400cc/380Nm |
|
Rope(D x L) |
6x20mm |
6x20mm |
|
Rope Speed(50 L/min hydraulic oil) |
45m/min |
45m/min |
|
Dimensions
|
Length: 500 mm Length with pendant 560 mm Front width: 120 mm Rear width: 180 mm Width of bearing: +50 mm Width motor: + 205 mm Height: 250 mm 560x435x250mm |
Length: 500 mm Length with pendant 560 mm Front width: 120 mm Rear width: 180 mm Width of bearing: + 50 mm Width motor: + 205 mm Height: 250 mm 560x435x250mm |
|
Weight |
50kg |
55kg |
-
