Model |
RT03A |
|
Crane |
|
|
Max. outreach |
4.2m |
|
Lifting capacity at full reach |
200kg |
|
Lifting capacity at 2 m (inc. grapple&rotator) |
430kg |
|
Telescopic boom |
0.8m |
|
Rotator Max. load |
10KN |
|
Grapple |
0.08m2 |
|
Slewing cylinder |
4pcs |
|
Slewing torque |
7KNm |
|
Slewing angle, |
360 ° |
|
Crane lifting damper System |
Standard |
|
Crane turning damper System |
Optional |
|
Working pressure |
18Mpa |
|
Hydralic winch |
Standard 50m(Romote control) |
|
Weight( without outriggers) |
345kg |
|
Trailer |
|
|
Max. loading capacity |
2000kg |
|
Trailer frame |
Double C-beam |
|
Total length |
4965mm |
|
Width |
1470mm |
|
Height |
1367mm |
|
Height of front plate(WxH) |
1497x810mm |
|
Loading area |
0.8m2 |
|
Loading area length |
2932mm |
|
Loading support”S” |
6 swivel |
|
Clearance |
437mm |
|
Outriggers type |
Hydrauli & Fold |
|
4WD Drive |
Standard(Remote control) |
|
Weight |
607kg |
|
Engine power unit |
|
|
Engine |
LIFAN 9HP Manual start |
|
Hydraulic tank capacity |
6L |
|
Hydraulic flow |
14.4L/min |
|
Working pressure |
18Mpa |
|
Packing size(Crane+trailer+power unit) |
2200x1400x1200mm |
|
Weight |
48kg |
|
N.W./G.W. |
1000/1100kg |
|
40” HC |
16pcs |
-
